Glass Laser Sandblasting Machine
Digital equipment for creating frosted areas, decorative patterns and customized surface effects on glass.
High-speed digital frosting and surface processing.
The glass laser sandblasting machine creates frosted areas, patterns and fine surface effects without conventional abrasive blasting media. A digital workflow supports repeatable designs for mirrors, decorative glass, privacy panels, film removal and selected marking tasks.
The supplied C/1224 platform is documented with a high-peak fibre laser, servo-driven motion, telecentric optical components, exhaust and dual-control water cooling. Final specifications must be confirmed in the commercial quotation because laser power, working range and options can change with the requested process.
Configuration options
- C/1224 machine platform with 140 W or 200 W laser configuration.
- Working envelope documented up to 1200 x 2400 x 50 mm.
- Optional vacuum suction fixture and project-specific workholding.
- Digital file workflow compatible with common vector-design formats.
- Export packing, installation guidance and operating training coordinated with the order.
Design and production notes
- Sample testing is recommended for coating removal, frosting depth and appearance approval.
- Glass type, coating, paint or film composition can change the required process settings.
- Exhaust routing, cooling water, ambient temperature and electrical supply must be prepared before installation.
- The buyer should confirm required throughput, file formats and operator workflow.
- Quoted performance and tolerances are confirmed against the selected machine configuration.
Technical overview.
Use this summary to prepare an inquiry. Final values, tolerances and compliance requirements are confirmed in the written quotation and approved drawing.
- Model
- C/1224 – 140 W or 200 W configuration.
- Working size
- Documented range up to 1200 x 2400 x 50 mm.
- Machine size and weight
- Approx. 3100 x 2100 x 800 mm; approx. 950 kg.
- Total power
- Approx. 4 kW; AC 190-240 V, 50-60 Hz.
- Laser and speed
- High-peak fibre laser; scanning line speed up to 12000 mm/s.
- Repeatability
- Mechanical: up to +/-0.25 mm; laser: up to +/-0.002 mm in the source specification.
Frequently asked questions.
These answers explain the normal selection process. Send the project drawing or sample when a definitive technical answer is required.
Can the machine process materials other than glass?
The source specification also lists selected coating-removal and surface-marking work on compatible metal materials. A sample should be tested before purchase.
Which laser power should I choose?
The choice depends on material, coating, effect, speed and duty cycle. Send representative samples and target output so the 140 W and 200 W options can be compared.
What utilities are required?
Plan for the confirmed electrical supply, exhaust ducting, cooling system, suitable ambient conditions and enough access space for loading and maintenance.
Built around your project.
Dimensions, processing and configuration can be reviewed according to the application, drawings, production requirements and destination market.
Digital pattern workflow
Custom working size
Repeatable decorative processing
Configuration consultation
Typical applications.
Share your project details with Jade Pure so our team can match the product or equipment configuration to the intended use.
