Colors Vertical Line Machine
Specialized equipment for applying decorative coloured line patterns to glass for doors, windows and interior design products.
Automatic decorative line application with selectable heads.
The colours vertical line machine applies consistent decorative lines to flat glass and selected hard materials. It was developed to improve line smoothness, corner quality, repeatability and material use compared with manual line drawing and colouring.
The documented C1224, C1824 and C2030 models cover progressively larger working formats. One, two or three dispensing heads can be selected, and the source material describes black, white and gold colour switching for decorative glass production.
Configuration options
- C1224 with documented working size up to 1220 x 2440 mm.
- C1824 with documented working size up to 1830 x 2440 mm.
- C2030 with documented working size up to 2000 x 3000 mm.
- Single-, double- or triple-head configuration by required output.
- Colour and line-pattern workflow confirmed by sample and production test.
Design and production notes
- The coating material, viscosity and curing method must match the intended substrate and service environment.
- Line width, corners, colour sequence and pattern file should be approved on a sample.
- Flatness and cleanliness of the workpiece influence line consistency and adhesion.
- Allow suitable drying or curing space downstream of the machine.
- The quotation should confirm included spare parts, heads, consumables and operator training.
Technical overview.
Use this summary to prepare an inquiry. Final values, tolerances and compliance requirements are confirmed in the written quotation and approved drawing.
- Models
- C1224, C1824 and C2030.
- Maximum formats
- 1220 x 2440, 1830 x 2440 or 2000 x 3000 mm by model.
- Drive and power
- Gear-rack / pneumatic system; documented 220 V, 450 W.
- Working environment
- Documented operating range of 20-50 degrees C.
- Processing speed
- Up to 10 m/min in the source specification.
- Head options
- One, two or three heads selectable.
Frequently asked questions.
These answers explain the normal selection process. Send the project drawing or sample when a definitive technical answer is required.
What colours can the machine apply?
The source material describes black, white and gold switching. Other materials or colours should be confirmed by sample testing.
How many dispensing heads are available?
The documented configurations offer one, two or three heads. The best choice depends on pattern, colour sequence and required output.
Can it process materials other than glass?
The source describes flat glass, marble and selected hard materials. Adhesion and curing should be tested on the actual substrate.
Built around your project.
Dimensions, processing and configuration can be reviewed according to the application, drawings, production requirements and destination market.
Decorative line processing
Pattern customization
Production-size configuration
Workflow consultation
